在本文中,我将向您展示如何使用 JavaScript 和 HTML5 Canvas创建绘图/绘图应用程序。

特征:

  1. 在Canvas画布上绘画
  2. 多种颜色
  3. 清除画布
  4. 将绘图另存为图像

首先让我们创建一个带有 canvas 元素的 index.html 文件。

<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <meta http-equiv="X-UA-Compatible" content="IE=edge">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <link rel="stylesheet" href="style.css">
    <title>www.linuxmi.com - JavaScript Drawing APP</title>
</head>
<body>
    <canvas id="canvas"></canvas>

    <script src="main.js"></script>
</body>
</html>

现在让我们创建具有基本重置的style.css

*{
    margin: 0;
    padding: 0;
}

最后,我们将创建我们的 main.js,我们将定位我们的画布并将其大小设置为我们的屏幕大小。

const canvas = document.getElementById("canvas")
canvas.height = window.innerHeight
canvas.width = window.innerWidth

// ctx 是我们画布的上下文
// 我们使用 ctx 在画布上绘制
const ctx = canvas.getContext("2d")

// 让我们创建一个矩形用于测试目的
ctx.fillStyle = "red"
ctx.fillRect(100, 100, 100, 100)

现在,如果我们在浏览器中打开它,我们应该会看到一个红色矩形。

好的,让我们删除这个矩形当使用者移动他的鼠标时我们想要得到鼠标的位置。我们可以使用mousemove事件。

const canvas = document.getElementById("canvas")
canvas.height = window.innerHeight
canvas.width = window.innerWidth

const ctx = canvas.getContext("2d")

window.addEventListener("mousemove", (e) => {
    console.log("Mouse X: " + e.clientX)
    console.log("Mouse Y: " + e.clientY)
})

现在我们还需要跟踪上一个鼠标位置,并从上一个鼠标位置到当前鼠标位置画一条线。

const canvas = document.getElementById("canvas")
canvas.height = window.innerHeight
canvas.width = window.innerWidth

const ctx = canvas.getContext("2d")

// previous mouse positions
// They will be null initially
let prevX = null
let prevY = null

// How thick the lines should be
ctx.lineWidth = 5

window.addEventListener("mousemove", (e) => {
    // initially previous mouse positions are null
    // so we can't draw a line
    if(prevX == null || prevY == null){
        // Set the previous mouse positions to the current mouse positions
        prevX = e.clientX
        prevY = e.clientY
        return
    }

    // Current mouse position
    let currentX = e.clientX
    let currentY = e.clientY

    // Drawing a line from the previous mouse position to the current mouse position
    ctx.beginPath()
    ctx.moveTo(prevX, prevY)
    ctx.lineTo(currentX, currentY)
    ctx.stroke()

    // Update previous mouse position
    prevX = currentX
    prevY = currentY
})

现在,如果您移动鼠标,您将看到将绘制一条线。但我们不希望这条线不受控制地绘制。所以我们将声明一个变量let draw = false。我们将只绘制draw 是 true

所以我们可以监听mousedownmouseup事件。并设置drawtrue用户按下鼠标时和false释放鼠标时。

const canvas = document.getElementById("canvas")
canvas.height = window.innerHeight
canvas.width = window.innerWidth

const ctx = canvas.getContext("2d")

let prevX = null
let prevY = null

ctx.lineWidth = 5

let draw = false

// Set draw to true when mouse is pressed
window.addEventListener("mousedown", (e) => draw = true)
// Set draw to false when mouse is released
window.addEventListener("mouseup", (e) => draw = false)

window.addEventListener("mousemove", (e) => {
    // if draw is false then we won't draw
    if(prevX == null || prevY == null || !draw){
        prevX = e.clientX
        prevY = e.clientY
        return
    }

    let currentX = e.clientX
    let currentY = e.clientY

    ctx.beginPath()
    ctx.moveTo(prevX, prevY)
    ctx.lineTo(currentX, currentY)
    ctx.stroke()

    prevX = currentX
    prevY = currentY
})

太棒了!现在让我们在 HTML 中添加一些按钮来更改颜色、清除画布和保存绘图。

<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <meta http-equiv="X-UA-Compatible" content="IE=edge">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <link rel="stylesheet" href="style.css">
    <title>Linux迷 www.linuxmi.com</title>
</head>
<body>
    <canvas id="canvas"></canvas>
    <div class="nav">
        <!-- We will be accessing the data-clr in JavaScript -->
        <div class="clr" data-clr="#000"></div>
        <div class="clr" data-clr="#EF626C"></div>
        <div class="clr" data-clr="#fdec03"></div>
        <div class="clr" data-clr="#24d102"></div>
        <div class="clr" data-clr="#fff"></div>
        <button class="clear">clear</button>
        <button class="save">save</button>
    </div>

    <script src="main.js"></script>
</body>
</html>

我们还需要在我们的 css 中设置它们的样式。

*{
    margin: 0;
    padding: 0;
}

.nav{
    width: 310px;
    height: 50px;
    position: fixed;
    top: 0;
    left: 50%;
    transform: translateX(-50%);
    display: flex;
    align-items: center;
    justify-content: space-around;
    opacity: .3;
    transition: opacity .5s;
}
.nav:hover{
    opacity: 1;
}

.clr{
    height: 30px;
    width: 30px;
    background-color: blue;
    border-radius: 50%;
    border: 3px solid rgb(214, 214, 214);
    transition: transform .5s;
}
.clr:hover{
    transform: scale(1.2);
}
.clr:nth-child(1){
    background-color: #000;
}
.clr:nth-child(2){
    background-color: #EF626C;
}
.clr:nth-child(3){
    background-color: #fdec03;
}
.clr:nth-child(4){
    background-color: #24d102;
}
.clr:nth-child(5){
    background-color: #fff;
}

button{
    border: none;
    outline: none;
    padding: .6em 1em;
    border-radius: 3px;
    background-color: #03bb56;
    color: #fff;
}
.save{
    background-color: #0f65d4;
}

成功后的页面应该看起来像这样。

现在,每当单击具有 clr 类的 div 时,我们都会添加以将线条的颜色设置为该 div 的 data-clr 属性。

const canvas = document.getElementById("canvas")
canvas.height = window.innerHeight
canvas.width = window.innerWidth

const ctx = canvas.getContext("2d")

let prevX = null
let prevY = null

ctx.lineWidth = 5

let draw = false

// Selecting all the div that has a class of clr
let clrs = document.querySelectorAll(".clr")
// Converting NodeList to Array
clrs = Array.from(clrs)

clrs.forEach(clr => {
    clr.addEventListener("click", () => {
        ctx.strokeStyle = clr.dataset.clr
    })
})

window.addEventListener("mousedown", (e) => draw = true)
window.addEventListener("mouseup", (e) => draw = false)

window.addEventListener("mousemove", (e) => {
    if(prevX == null || prevY == null || !draw){
        prevX = e.clientX
        prevY = e.clientY
        return
    }

    let currentX = e.clientX
    let currentY = e.clientY

    ctx.beginPath()
    ctx.moveTo(prevX, prevY)
    ctx.lineTo(currentX, currentY)
    ctx.stroke()

    prevX = currentX
    prevY = currentY
})

OK!现在让清除按钮起作用。 所以当我们点击它时,它应该清除我们的画布。

const canvas = document.getElementById("canvas")
canvas.height = window.innerHeight
canvas.width = window.innerWidth

const ctx = canvas.getContext("2d")

let prevX = null
let prevY = null

ctx.lineWidth = 5

let draw = false

let clrs = document.querySelectorAll(".clr")
clrs = Array.from(clrs)
clrs.forEach(clr => {
    clr.addEventListener("click", () => {
        ctx.strokeStyle = clr.dataset.clr
    })
})

let clearBtn = document.querySelector(".clear")
clearBtn.addEventListener("click", () => {
    // Clearning the entire canvas
    ctx.clearRect(0, 0, canvas.width, canvas.height)
})


window.addEventListener("mousedown", (e) => draw = true)
window.addEventListener("mouseup", (e) => draw = false)

window.addEventListener("mousemove", (e) => {
    if(prevX == null || prevY == null || !draw){
        prevX = e.clientX
        prevY = e.clientY
        return
    }

    let currentX = e.clientX
    let currentY = e.clientY

    ctx.beginPath()
    ctx.moveTo(prevX, prevY)
    ctx.lineTo(currentX, currentY)
    ctx.stroke()

    prevX = currentX
    prevY = currentY
})

差不多好了! 现在我们要做的就是在单击保存按钮时保存我们的绘图。

所以这是最终的 JavaScript 代码

const canvas = document.getElementById("canvas")
canvas.height = window.innerHeight
canvas.width = window.innerWidth

const ctx = canvas.getContext("2d")

let prevX = null
let prevY = null

ctx.lineWidth = 5

let draw = false

let clrs = document.querySelectorAll(".clr")
clrs = Array.from(clrs)
clrs.forEach(clr => {
    clr.addEventListener("click", () => {
        ctx.strokeStyle = clr.dataset.clr
    })
})

let clearBtn = document.querySelector(".clear")
clearBtn.addEventListener("click", () => {
    ctx.clearRect(0, 0, canvas.width, canvas.height)
})

// Saving drawing as image
let saveBtn = document.querySelector(".save")
saveBtn.addEventListener("click", () => {
    let data = canvas.toDataURL("imag/png")
    let a = document.createElement("a")
    a.href = data
    // what ever name you specify here
    // the image will be saved as that name
    a.download = "sketch.png"
    a.click()
})

window.addEventListener("mousedown", (e) => draw = true)
window.addEventListener("mouseup", (e) => draw = false)

window.addEventListener("mousemove", (e) => {
    if(prevX == null || prevY == null || !draw){
        prevX = e.clientX
        prevY = e.clientY
        return
    }

    let currentX = e.clientX
    let currentY = e.clientY

    ctx.beginPath()
    ctx.moveTo(prevX, prevY)
    ctx.lineTo(currentX, currentY)
    ctx.stroke()

    prevX = currentX
    prevY = currentY
})

OK,我们已经成功完成了。
